For sale is ONE (1) Miranda frame populated with 9x HDC-1861 Downconverter & DA cards. Good working condition. All cards have OPT: Audio license. Frame has two power supplies plus CPU-ETH Frame controller. All corresponding backplanes are included. The fans may need to replaced for 24H operation as they start to make noises. There are some scratches and signs of use. Actual photos are showed. Power cords are not included unless otherwise mentioned. If you are looking for any other Miranda modular cards - we probably have them. Thousands of cards available. Check out our inventory.
The 2 RU Densité 2 Frame can simultaneously process 3G, HD, SD and analog video, as well as AES and analog audio. Its front-opening frame features dual hot-swappable power supplies (PSUs) and fans. Modules for the air-cooled frame are also hot swappable, and replacement modules can be configured automatically. All modules, redundant PSUs and fans are monitored to deliver status via GPI or an Ethernet port. Front panel multicolor LEDs provide status reporting, while a controller card allows card adjustments from the front panel.
The HDC-1861 is an HD monitoring downconverter as well as a distribution amplifier, with an analog monitoring output. The HDC series cards are dual rate for hybrid HD/SD facilities. The DA section provides up to 4 HD reclocled outputs, and the HD downconverter supports multiple formats of signals, such as 1080i, 720p, 23.98 psf. All Metadata (TC, CC) and audio (2 groups) are processed in HD and SD. When SD is set at the input, the card offers ARC functionality with five presets. The SDI output can add on screen display of Time Code, input format as well as graticules and markers.
